HIGH-CAPACITY ELECTRIC FORKLIFT

Models
J155-190XNL
Capacity
7000-9000kg

The Hyster® J155-190XNL sit-down counterbalanced forklift powered by integrated lithium-ion technology is designed to satisfy a need for a zero emission alternative in a high capacity range for both indoor and outdoor operation. Integrated lithium-ion power is a suitable solution for heavy-duty applications, providing ICE-like performance with zero emissions.

  • Energy efficient
  • Ergonomic operator compartment
  • Low cost of operation
  • J155-170XNSL models
Industry Sector

Suitable for use both indoors and outside, this series of tough electric trucks is suitable for a number of industries including automotive, timber, metal, beverage, paper, bottling and more.

Start a quote

Interested in more information on this lift truck? Our solutions team is available to discuss your specific application and how this product can meet your needs.

Start a quote

GOOD DESIGN AWARD

The J155-190XNL series earned the top spot in the lift trucks and accessories category as a high-performance, zero emission alternative for heavy-duty, higher-capacity applications that have traditionally relied on internal combustion engines.

Learn more

Powerful and energy efficient

High Capacity Performance on Hyster Electric Powered Forklift

Energy efficient

The battery fully charges from lift lock-out (12% state of charge) in less than 90 minutes with the required 50kW charger, and once charged, it stays over 90% efficient throughout operation.

Ergonomic operator compartment

The strategic design that incorporates the integrated lithium-ion battery creates more space in the operator compartment, maximizing comfort and convenience to help propel productivity.

  • Extra space allows the option for Air-Ride Seats for a smoother ride and operator comfort.
  • With no ICE engine running, truck noise levels are much quieter and there are no emissions
  • Low intermediate step height for easy three-point entry and exit.
  • Highly adjustable steering column and ergonomically positioned operators seat with integrated armrest incorporating mini-levers for hydraulic control and other key functions.
  • The dash display transmits continuous feedback to the operator of the truck’s status and is positioned for optimum visibility.
Low cost of operation

Lithium-ion power is an ideal solution for heavy-duty applications due to the sealed battery requiring no battery maintenance, faster charging, and longer overall battery cycle life when compared to typical lead-acid batteries.

If you are operating separate indoor and outdoor trucks, utilizing the J155-190XNL can cut your fleet in half. Why? Because this truck is designed to work in both indoor and outdoor applications.

J155-170XNSL MODELS

J155-170XNSL truck models with a short counterweight are available to give extra maneuverability in applications where space is in short supply. The shortened counterweight and Turn Assist System helps provide an outstanding minimum outside turning radius and right angle stack.

Model Load Capacity Load Centre Lift Height Turning Radius Battery Capacity
J155XNL 7000kg 600mm 6200mm 3080mm 350V Integrated Lithium-Ion / Traction Motor Type - Permanent Magnet(V/Ah)
J175XNL 8000kg 900mm 5965mm 3145mm 350V Integrated Lithium-Ion / Traction Motor Type - Permanent Magnet(V/Ah)
J170XNL 8000kg 600mm 5965mm 3145mm 350V Integrated Lithium-Ion / Traction Motor Type - Permanent Magnet(V/Ah)
J190XNL 9000kg 600mm 5965mm 3723mm 350V Integrated Lithium-Ion / Traction Motor Type - Permanent Magnet(V/Ah)
