Empty Container Handler
Reliability and performance in Empty Container Handling
- Models
- H8XD-EC6 - H11XD-ECD9
- Capacity
- 8000-11000kg
Designed to perform and last while handling heavy double container loads. With components designed for double handling, imagine what they can do in your single handling application.
- Optimized powertrain
- Single and double handling spreaders
- Spacious, comfortable operator environment
- Superb visibility
- Simplified serviceability
Container Stacking Up to 9 High
Optimized Powertrain
Single and double handling spreaders
Spacious, comfortable operator environment
Superb visibility
Simplified serviceability
- Stage V integrated powertrain offers excellent fuel economy and maximum productivity.
- On-demand hydraulics keep oil temperature lower to protect hydraulic components.
- Automatic throttle-up on hoist and tilt enables engine to operate in most efficient rpm range.
- Drive train offers features that protect itself from excessive temperatures and pressures
- Container sensing system supports safer handling when transporting two containers.
- Centralized greasing on the spreader reduces the number of grease points for easier maintenance.
- Smart camera systems are available for additional operator support.
- Ample sideshift allows operators to easily reposition offset loads and handle two reefers with the gen set on the same side.
- Ergonomically designed controls help elevate productivity while minimizing operator fatigue.
- Spacious cockpit style cabin that keeps all truck information and controls within reach.
- Variety of seat configurations such as mechanical or air suspension, cloth or vinyl cover, and lumbar support.
- Ergonomically designed, seat-mounted control arm.
- More precise and efficient load handling.
- Optional raised cabin allows the operator to view and inspect the top of the container.
- Tempered top glass creates optimum visibility for container stacking.
- Designed with the service technician in mind.
- Easy access to the engine, hydraulics, and other major components.
- Tip back cabin provides ample service access.
| Model | Load Capacity | Load Centre | Lift Height | Turning Radius | Overall Width | Weight | Engine | Transmission |
|---|---|---|---|---|---|---|---|---|
| H8XD-EC6 | 8000kg | 1220mm | 16164mm | 6371mm | 4110mm | 35558kg | MTU 7.7L Diesel | ZF - 5WG211 |
| H8XD-EC7 | 8000kg | 1220mm | 18764mm | 6371mm | 4110mm | 36912kg | MTU 7.7L Diesel | ZF - 5WG211 |
| H9XD-ECD8 | 9000kg | 1220mm | 18922mm | 6371mm | 4110mm | 40582kg | MTU 7.7L Diesel | ZF - 5WG211 |
| H9XD-EC8 | 9000kg | 1220mm | 21364mm | 6371mm | 4335mm | 41487kg | MTU 7.7L Diesel | ZF - 5WG211 |
| H9XD-EC7 | 9000kg | 1220mm | 18764mm | 6371mm | 4110mm | 38898kg | MTU 7.7L Diesel | ZF - 5WG211 |
| H9XD-ECD7 | 9000kg | 1220mm | 16322mm | 6371mm | 4110mm | 39468kg | MTU 7.7L Diesel | ZF - 5WG211 |
| H10XD-ECD8 | 10000kg | 1220mm | 18922mm | 6371mm | 4335mm | 41886kg | MTU 7.7L Diesel | ZF - 5WG211 |
| H11XD-ECD8 | 11000kg | 1220mm | 18922mm | 6371mm | 4335mm | 42847kg | MTU 7.7L Diesel | ZF - 5WG211 |
| H11XD-ECD9 | 11000kg | 1220mm | 21522mm | 6371mm | 4335mm | 44198kg | MTU 7.7L Diesel | ZF - 5WG211 |
