High Capacity Internal Combustion Trucks Pneumatic Tire

Heavy Duty Forklift Truck Pneumatic Tire

Big Trucks for Heavy-Duty Applications

Modelos
H280-330XD48, H360XD(S)36, H360XD(S)48, H400XD
Capacidad de carga
12701-18144kg

Heavy-duty forklifts for your harshest applications.

  • Robust design
  • Excellent visibility
  • Operator comfort
  • Low cost of ownership
  • Easily serviceable
Industry Sector

- Breakbulk
- Lumber
- Concrete
- Steel, Aluminum & Metals
- Mining, Energy & Construction

Pregunte a los expertos

¿Le interesa ver más información sobre este montacargas? Nuestro equipo de soluciones está disponible para hablar sobre su aplicación específica y sobre cómo se pueden satisfacer sus necesidades con este producto.

Iniciar una cotización

Built to be Tough

Engineered for maximum dependability in the most demanding applications.

Robust design

The truck has been engineered for long load centers, wide loads and heavy duty-cycle conditions. Oversized and reinforced mast channels, rollers, stub shafts and chain anchors cater to heavy duty applications. A special purpose-built mast design for this truck series has been developed from the ground up featuring less mast deflection than comparable products with overhead tilt.

The steer axle is designed for longer life, providing an adjustable outside turning radius which reduces stress on the axles and improves tire life by mitigating tire scrubbing.

Excellent visibility

Open carriage design, mast chains mounted on the outside of the mast low cowl and increased space between mast channels and valve block location enable enhanced forward view of fork tips at travel and load height.

Curved, scratch resistant, tempered glass front and rear windshields, FOPS certified armored glass top window and one piece steel-framed glass doors provide operators with excellent all-around visibility. On the exterior, sloping counterweights enhance visibility of steer tires for improved maneuverability and reduced tire gouging.

Operator comfort

The ergonomically designed high visibility cab puts greater productivity within easy reach. Equipped with an armored glass top window, curved front and rear windows and steel doors with tempered glass, the operator cab provides excellent all-around visibility. Inside the cab there is more space with the largest entry area in the industry, more control with a full-color screen displaying performance data at the operator’s fingertips and more comfort with an exclusive lateral sliding seat, adjustable steering column and foot pedal, plus ergonomic controls.

Low cost of ownership

Fuel consumption is a key driver of the total cost of ownership for heavy duty lift trucks. Hyster high capacity lift trucks are engineered with integrated powertrain system and on-demand hydraulics to deliver low fuel consumption with high levels of productivity.

The engine design produces more power and torque using XPI high-pressure, common-rail fuel injection and variable geometry turbochargers. Advanced controls enable the engine to provide peak performance and operating efficiency while delivering great fuel economy and durability.

Easily serviceable

Hyster forklifts are designed with the service technician in mind. Gull-wing hoods provide quick access to key components, and daily checks don’t require tilting the cab. A tilting cab provides easy access to hydraulic components in seconds. Galvanized, broad, slip-resistant running boards foster quick daily checks, while a large access bay enables easy radiator cleaning.  A hydraulic sight gauge makes for at-a-glance fluid level checks.

Modelo Capacidad de carga Centro de carga Altura de elevación Radio de giro Ancho promedio Peso Tipo de motor Transmisión
H280XD48 12701kg 1219mm 3750mm 4948mm 2540mm 1942kg Cummins QSB 6.7L Diesel ZF WG161
H330XD48 14969kg 1219mm 3984mm 4874mm 2540mm 22273kg Cummins QSB 6.7L Diesel ZF WG161
H360XD36 16329kg 914mm 3984mm 5184mm 2540mm 20926kg Cummins QSB 6.7L Diesel ZF WG161
H360XD48 16329kg 1219mm 3984mm 5184mm 2540mm 22601kg Cummins QSB 6.7L Diesel ZF WG161
H360XDS36 16329kg 914mm 3984mm 4874mm 2540mm 21574kg Cummins QSB 6.7L Diesel ZF WG161
H360XDS48 16329kg 1219mm 3984mm 4874mm 2540mm 23381kg Cummins QSB 6.7L Diesel ZF WG161
H400XD 18144kg 610mm 3984mm 4847mm 2540mm 20817kg Cummins QSB 6.7L Diesel ZF WG161
